Sun sensor, also called solar sensors or sun trackers, are optical instruments that detect the sun’s position relative to a satellite. By measuring sunlight’s angle and intensity, these sensors provide real-time data, aiding the attitude determination and control system (ADCS).
How Do Sun Sensors Work in Satellites?
Sun sensors in satellites operate based on photoelectric detection. Typically, a sun sensor consists of photodiodes, lenses, or slits to capture sunlight. When sunlight hits the sensor, it generates an electrical signal proportional to the incident angle. These signals are processed by the satellite’s onboard computer to calculate the sun vector—a three-dimensional representation of the sun’s direction from the satellite’s perspective.
– Coarse Sun Sensors (CSS): These offer a wide field of view (often up to 180 degrees) for initial acquisition during satellite tumbling or disorientation. Although less precise, they are critical for initiating attitude control.
– Fine Sun Sensors (FSS): Once the satellite stabilizes, fine sensors take over, with a narrower field of view (about 10-30 degrees) and higher accuracy, often better than 0.1 degrees. They use advanced algorithms to filter stray light or reflected noise.
– Analog Sun Sensors: These employ simple photodetectors to produce analog voltage outputs. They are cost-effective and lightweight, ideal for small satellites like CubeSats. However, temperature variations and aging effects limit their accuracy.
– Digital Sun Sensors: Using charge-coupled devices (CCD) or complementary metal-oxide-semiconductor (CMOS) imagers, digital sensors deliver high resolution and process images to precisely detect the sun’s centroid. They are common in geosynchronous satellites where accuracy is vital.
– Sun Presence Detectors: A basic variant, these confirm the sun’s visibility for power management to activate solar arrays.
– Quadrant Sun Sensors: Divided into four quadrants, these sensors measure light distribution to determine angular offset. They are reliable for medium-accuracy applications in military reconnaissance satellites.
– MEMS-Based Sun Sensors: Leveraging microelectromechanical systems (MEMS), these sensors are compact and power-efficient, perfect for nanosatellites in constellations like Starlink.
– Communication Satellites: In geosynchronous orbits, sun sensors maintain antenna alignment, ensuring continuous signals for television and internet services.
– Earth Observation Satellites: Platforms like Landsat rely on sun sensors to orient cameras for high-resolution imaging, supporting environmental monitoring and disaster response.
– Navigation and GPS Satellites: Sun sensors aid autonomous navigation, reducing reliance on ground stations and enhancing resilience against interference.
– Space Exploration Probes: Mars rovers, like Perseverance, integrate sun sensors for daytime orientation, complementing inertial measurement units.
